Our Asus Prime X570 Pro review shows how this feature-laden motherboard is designed to adapt to different tasks. Although the Prime X570 pro looks less aggressive, it stands out for its subtle yet appealing aesthetics.
Also, users benefit from 5-way optimization, enhanced power solutions, and an AMD AM4 socket ready for AMD Ryzen 5000 Series.
Let’s find out more about this Asus Prime motherboard in this complete guide!
|Sleek and minimal design||No wifi|
|Metal-reinforced PCI-Express slots|
|Good overall performance|
|Unparalleled memory overclocking|
- 1 Prime X570 Pro Product Highlights
- 2 Asus Prime X570 Pro Review
- 3 How Has Asus Prime X570 Pro Evolved?
- 4 Asus Prime X570 Pro Features Breakdown
- 4.1 – Full-Length PCIE 4.0 Slots Gives High-Performance Data Rate
- 4.2 – Memory Capacity Is Expandable to 128 GB
- 4.3 – System Optimization and Overclocking Means One-Click Mechanism
- 4.4 – Unique Cooling Is Designed for Air and Liquid
- 4.5 – Multiple Ports Mean Superior Connection Options
- 4.6 – Processor Compatibility 2nd and 3rd-Gen Ryzen Processors
- 4.7 – Graphic and GPU Support
- 4.8 Conclusion
Prime X570 Pro Product Highlights
The Prime X570 Pro offers the most sought-after features of high-end motherboards at an affordable price. Below are some of the features you can enjoy from this motherboard:
- Socket: AMD AM4
- Chipset: X570
- Form Factor: ATX
- Memory: 4x DIMM, Support Dual Channel DDR4-4400 (OC) MHz
- USB Ports: 4x USB 3.2 Gen 2 ports(USB 3.2 Gen 2 Type-A & Type-C), 4x USB 3.2 Gen 1 port.
- PCIe 4.0: Dual M.2 slots
- Ethernet / Controller: 1 x Intel I211-AT Gigabit
- Storage: 6x SATA 6 Gb/s port, 2x M.2 port (SATA3/PCIe 4.0 x4)
- Cooling Options: Seven fan headers
- AMD Socket AM4 Chipset: Ready for AMD Ryzen 5000 Series, 4000 G-Series/ 3000 Series and 3000 G-Series, 2000 Series, and 2000 G-Series desktop processors
- 5-Way Optimization: Cool and overclock with one click
- Lighting: Aura Sync RGB
- Power connectors: 12V 8+4 pin connectors from PSU to the processors.
The Prime X570 Pro features the AMD AM4 socket that houses the latest Ryzen processor with up 16 cores and higher bandwidth. The AMD X570 chipset delivers magnificent overclocking capabilities. Intuitive cooling, stable power, and flexible transfer options boost your productivity. For this exceptional capability, we gave it a score of 9 out of 10.
The Asus Prime x570-Pro RAM compatibility is impressive. You get dual-channel DDR4 RAM, maxed at 128 GB. With four slots, you can install RAM sticks of different capacities to get the best performance. Furthermore, the 4400 MHz overclocking capability allows for faster performance and is typical of high-end systems.
This gives speedier performance when juggling between different processes or when handling graphic and media-intensive tasks. For its ability to accommodate large RAM, we gave it a 9 out of 10.
This motherboard has both the x16 PCI Express 4.0 and 3.0 lanes, which allow you to get the correct speed for your different peripherals. For instance, the dual PCIe 4.0 M.2 Slot supports up to 64GB/s, a superb performance. The 3.0 lanes allow you to use lower processors, such as Ryzen 3000 series, without changing hardware.
Therefore, this motherboard offers numerous customization and upgrade options when you want to go beyond preloaded features like graphics and storage. For this reason, we gave it 9 out of 10.
How Has Asus Prime X570 Pro Evolved?
Prime X570 Pro has evolved in compatibility for different Ryzen processors. You can use it out of the box with both Ryzen 3000 and 5000 chips — you will not need any changes to the bios. Furthermore, this motherboard comes with impressive feature-rich and straightforward bios. This is unlike its predecessor.
Again, the overclocking potential is awe-inspiring. The board overclocks perfectly on all Ryzen 3 and Ryzen 5 processors. If you enjoy tinkering, overclocking on this motherboard can be a thing to try, but it has one-click overclocking, where the board will do it for you for extra performance.
The PCI Express 4.0 offers way more bandwidth than its predecessor for your M.2 drives and GPU. Users have reported improved data transfer speeds and performance, especially for gaming and other graphic-intensive activities, compared to its predecessors.
Asus Prime X570 Pro Features Breakdown
Here is a complete breakdown of this motherboard’s impressive features.
– Full-Length PCIE 4.0 Slots Gives High-Performance Data Rate
The Prime X570-Pro has three full-length PCIe 4.0 slots that run at x16, x8/x8, and x8/x8/x4. This facilitates faster data transfer from graphics cards, RAID cards, NVMe SSDs, and other expansion cards. Furthermore, the board has three PCIe 4.0 x1 slots, with the motherboard’s storage capabilities coming through two PCIe 4.0 x4 M.2 slots. The bottom slot has a heat sink.
Since compute-intensive, data-intensive, and high-end applications require better performance from GPUs and other PCIe expansion cards, PCIe Gen 4 cuts the mustard. The PCI Express 4.0 offers more bandwidth for your M.2 drives and GPU and may offer the best data transfer speeds when paired with the correct processors.
It supports x16 PCI Express 4.0/3.0 lanes, but if you opt for the PCIe 4.0 x16, you get a slot with a 16-lane configuration, giving you data rates of up to 16 GT/s. So if you are a multi-tasker or involved in intensive graphical tasks, this might be the right motherboard.
– Memory Capacity Is Expandable to 128 GB
The ability to support up to 128 GB of RAM in four memory slots of dual-channel DDR4 RAM gives you immense flexibility to select the right RAM for your tasks. The four slots give more channels to attach your RAM stick, resulting in wider bandwidth, faster data transfer, and improved performance. For instance, you can install 8GB of RAM for internet browsing and casual computer usage, 16GB for casual gaming and less intensive multimedia tasks, or at least 32GB for serious gaming and multimedia tasks.
Remember, DDR4 offers higher overall speed with less voltage and increased transfer rates. This translates to overall less power consumption. Besides that, expandable RAM ability allows for upgradability since you can expand the total RAM capacity anytime, so this is the board to buy if you run memory-intensive tasks on your PC.
So, is Asus prime x570-pro good for gaming? While it is not built with an extreme focus on gaming, it is still a performance superstar — it would be better for casual gaming. Therefore, if you want an Asus prime x570-pro for gaming, use it to learn the details of the game.
– System Optimization and Overclocking Means One-Click Mechanism
The one-click optimization feature is ideal for those who prefer not to tinker with their system. The one-click mechanism is responsible for complex tuning and will dynamically optimize all the essential components of your system, providing suitable overclocking potentials.
Additionally, it has a stress test function that detects stress levels within your system and optimizes and overclocks the system for CPU- or memory-hungry workloads.
– Unique Cooling Is Designed for Air and Liquid
Keeping the Asus X570 Pro Prime cool is essential in maintaining system integrity. The system features an automated tuning utility to optimize cooling profiles based on your needs. A unique feature is that the fans stay quiet while delivering optimal airflow, even when handling graphics and CPU-intensive tasks, so you will not encounter loud whirring noises from your machine.
The suite of comprehensive cooling controls is configurable through the Fan Xpert 4 or the UEFI BIOS. The Fan Xpert lets you adjust the setting of the CPU and housing fan to achieve the finest heat dissipation performance. Since there are multiple temperature sources, use the Fan Xpert to map the temperature of the supported graphics unit to customize cooling for GPU and CPU-intensive tasks.
The dedicated header for AIOs is at the top, and at the bottom is a 3A pump header to power your custom water-cooled setup, but it can also be an alternative location for AIO or a hybrid GPU. Furthermore, a dedicated integrated circuit protects each fan header from over-temperature and over-current. Because fo this, you will not encounter unexpected shutdowns or slowdowns due to high temperatures and frying in case of over-current.
With PCIe 4.0, there is more heat than in the previous generation. Therefore, X570-Pro has an actively cooled heatsink to prevent throttling during sustained transfers. The Chipset Heatsink solution has a low-noise Delta Superflo fan, a finned heatsink, and a specially-designed air duct. The M.2 heatsink will also keep your SSD chilled.
– Multiple Ports Mean Superior Connection Options
The ASUS X570-Pro has several USB ports to enhance functionality regardless of the chipset. If you use the AMD X570 chipset, you get one USB 3.2 Gen 2 front panel connector port, four USB 3.2 Gen 2 ports at the back panel (3 x Type-A+1 x Type-C), two USB 3.2 Gen 1 ports (mid-board) and four USB 2.0 ports (mid-board).
The native USB 3.2 Gen 2 provides up to 10Gb/s, which is an amazing speed, especially for large files. Users appreciate multiple ports as they connect extra hardware on the motherboard at a go.
Ryzen 3000 APUs and the Ryzen 2400/2200G users will appreciate the HDMI and DisplayPort video outputs. Additionally, a PS/2 keyboard, mouse combo port, five 3.5 mm audio jacks, an Intel I211-AT Gigabit powered Ethernet port, and S/PDIF optical output driven by a Realtek S1220A HD audio codec.
– Processor Compatibility 2nd and 3rd-Gen Ryzen Processors
The AMD X570 chipset supports 2nd and 3rd-Gen Ryzen processors with an AM4 socket like the Asus Tuf Gaming x570-Plus. Processors designed for this board include Ryzen 5000, 3000, 4000, and a few 2000 series CPUs without Radeon Graphics. This wide spectrum allows you to choose a processor that fits your budget and performance needs.
Third-generation Ryzen processors have more cores and bandwidth, demanding more power than ordinary desktop CPUs. The X570-Pro has all it takes to handle these high-core-count processors while offering stable power to ensure optimal performance.
AMD shifted from 12nm Zen+ architecture in the second generation to the more efficient 7nm Zen 2 microarchitecture in the third generation. They support 16 cores, have more cache, better pre-fetch and fetch, a better frontend pipeline, and a more extensive register. With this in mind, you have the flexibility of getting the best processor for this motherboard.
– Graphic and GPU Support
The AMD X570 chipset supports Radeon Vega Graphics Processors. This GPU is integrated into Ryzen desktop processors compatible with Prime X570 Pro, giving you incredible power from one chip. Typically, you will not need separate processors and graphics units. This is a perfect setup for those with a small form factor computer.
Furthermore, the compatible processors allow multi-GPU configurations, including AMD 3-Way CrossFireX and NVIDIA SLI. These technologies combine the GPUs’ powers to improve performance by speeding up the rendering of 3D graphics. If you engage in 3D graphics, you will benefit a lot from this technology.
The x570-pro features other standout features, such as Armoury Crate, which gives you centralized control of supported devices. Also, you get the UEFI BIOS, which allows you to set up all devices programs effortlessly. However, you will need Asus prime x570-pro drivers for all peripheral devices.
The Prime X570-Pro is more suited to users looking to avoid gaming-themed Asus models, such as Asus Rog Strix X570-E Gaming. X570-Pro offers elegant and neutral designs, which look good with the smart RGB that makes the white rear panel cover pop.
Besides that, it offers above-par performance. Enthusiasts and overclockers demand the best from the AMD AM4 platform and find their needs sorted in this motherboard. So, if you are looking for an X570 motherboard, we highly recommend the ASUS X570-PRO.
